Total solar eclipse 22 Nov 1984
Papua New Guinea

Main Entrance Astrophotography Genealogy Library
Chronology Museum History Reference Museum Index
1984 Solar Eclipse, time lapse, 29Kb 1273x443
Copyright (c) 1984 Hiram Clawson
Multiple exposure photograph of the entire eclipse.
1273x443 JPEG image, 29Kb
Copyright (c) 1984 Hiram Clawson
Camera: Nikon FM-2
Lens: 50 mm f 1.2
Film: KODAK ASA 25 color slide film
Shutter speed: 1/4000 sec partial images, about 6 seconds for the central image
f stop: f/16 for all images
Filter: partial phases: Neutral Density filters #8 + #4
Filter: no filters for the central image
Location: Papua New Guinea
Scanner: HP PhotoSmart scanner
Image Processing: ImageMagick
Notes: Interval between images is 10 minutes starting at 20:21:00 UT. The central exposure is at 21:22:30 which is 1m30 off of the center of the sequence but is in the middle of this 57 second eclipse. The images are a bit fuzzy because they are overexposed. A mistake I repeated in 1994, I need to stack more neutral density filters. After the sequence was finished, an image of the blue sky was made at f16 and 1/1000 second but that wasn't enough to expose the film. I didn't understand this at the time, but after doing a multiple exposure image with this camera, the light meter will not give a reading. To take an after picture requires a separate light meter. I now use one of the other cameras after the eclipse with the same f stop and ASA settings.
